BMW wheel style 71

The BMW wheel style 71 is part of bmw’s lineup of original wheel styles.
The bmw Style 71 wheel is available in diameters of 17″ and 18″ inches, with a bolt pattern of 5×120.
This is the original wheel style for the bmw series E36, E46, Z3, E39 and E60, however it might fit other models given the specifications match below with the replacement wheel.The style given to this wheel is best described as Double Spoke Split Rim.

BMW wheel style 71

BMW wheel style 71 Technical Specifications & Parts

Wheel StyleNrPart NumberPart NamePart Details
710236 11 9 416 895Two-piece light alloy rim8JX18 ET:472
710236 11 9 416 896Two-piece light alloy rim81/2JX18 ET:502
710336 11 6 752 091Two-piece light alloy rim71/2JX17 ET:412
710336 11 6 752 092Two-piece light alloy rim81/2JX17 ET:502
710336 11 1 097 186Two-piece light alloy rim8JX18 ET:472
710336 11 1 097 187Two-piece light alloy rim81/2JX18 ET:502
710336 11 6 760 821Two-piece light alloy rim8JX17 ET:474
710436 13 1 095 390Wheel bolt blackM12X1,520
71?36 13 6 781 150Wheel bolt blackM12X1,520
710536 13 6 768 640Hub Cap with clipped-on plaque4
71?36 11 1 095 436Valve caps RDC4
71?36 13 6 783 536Hub cap with chrome edgeBMW4
710636 13 6 767 547BMW insignia stamped/painted4
710736 12 1 116 326Rubber valveL=42,5MM4
710736 12 1 178 869Rubber valveL=48,5MM4
710736 11 1 095 375Screw-in valve, RDC4
71?36 14 6 792 829Screw-in valve, RDC4
710736 14 6 792 831Screw-in valve, RDCGELB4
710836 14 1 095 389Valve4
710936 12 1 120 779Valve caps4
710936 14 6 774 590Valve caps RDC4
710236 11 6 761 995Two-piece light alloy rim8JX18 ET:204
BMW models for which the BMW wheel style 71 fits: E46 E39 E60+ E36 E85+
More images

Will the BMW wheel style 71 fit on your BMW?

Bear in mind that it could be dangerous to run your BMW on tires or wheels they aren’t designed to fit. If you are unsure about your current wheel specifications, please check our BMW wheel fitment chart and guide



Insert your existing BMW wheel and tire dimensions, and the sizes of the BMW wheel style 71, and the outcome will be shown on the diagram. The strut shown in the diagram below is for illustration purpose only.

YOUR EXISTING SETUP
Existing Tyre
Existing Wheel

Above values are only examples! If unsure of your current wheel size? Check here!

YOUR NEW SETUP
Existing Tyre
Existing Wheel

Above values are only examples! Change values to view fittment.

YOUR RESULTS

are automatically applied below


The diagram is only for show to help you visualize your tires and wheel fitment of your new setup.


Tire Width - The width of your tire in millimeters. 195/55ZR15

Tire Profile - The ratio of tire wall width to tire width. 195/55ZR15

Tire Diameter - The diameter of your wheels in inches. 195/55ZR15

Offset - the distance from the center of the wheel to the mounting face in mm. ET20

Rim Width - The width of your rims in inches. 7.5JX17

InchesOriginal WheelNew WheelDifference
Diameter%
Circumference%
Sidewall%
Width%
Wheel Revolutions

What is the recommended tire pressure for the BMW wheel style 71?

The tire pressure for the BMW wheel style 71 will depend on your BMW model. Most BMW models like the BMW 3 Series and the BMW 5 Series, have a recommended tire pressure of 32 PSI (2.2 Bar). However, you should always double-check this for your specific BMW model. You can find out the recommended tire pressure for your BMW, by checking the the sticker on the inside edge of the driver’s door or, check your owner’s manual if you still have the same type of tires that came with the vehicle.
