BMW wheel style 32

The BMW wheel style 32 is part of bmw’s lineup of original wheel styles.
The bmw Style 32 wheel is available in diameters of 15″, 16″, 17″, 18″ and 20″ inches, with a bolt pattern of 5×120.
This is the original wheel style for the bmw series E39, E36, E46, Z3, E34, E87, E90, E38, E60 and E65, however it might fit other models given the specifications match below with the replacement wheel.The style given to this wheel is best described as Radial-Styling.
Notes: *Brillant-Line

BMW wheel style 32

BMW wheel style 32 Technical Specifications & Parts

Wheel Style Nr Part Number Part Name Part Details
32 02 85 32 9 408 696 Light alloy rim “Brilliantline” 8JX17 ET:47 4
32 02 85 32 9 408 697 Light alloy rim 8JX18 ET:47 2
32 02 85 32 9 408 698 Light alloy rim 8 1/2JX18 ET:50 2
32 02 85 32 9 409 954 Light alloy rim “Brilliantline” 7JX15 ET:47 4
32 03 36 11 1 095 337 Light alloy rim “Brilliantline” 8JX17 ET:47 4
32 03 36 11 1 095 340 Light alloy rim 8JX18 ET:47 2
32 03 36 11 1 095 341 Light alloy rim 81/2JX18 ET:50 2
32 03 36 12 1 093 891 Light alloy rim “Brilliantline” 7JX15 ET:47 4
32 03 36 11 6 750 869 Light alloy rim “Brilliantline” 7JX16 ET:46 4
32 03 36 11 1 094 638 Light alloy rim 7JX16 ET:46 4
32 04 36 13 6 781 150 Wheel bolt black M12X1,5 X
32 05 36 13 6 783 536 Hub cap with chrome edge BMW 4
32 06 36 13 6 767 547 BMW insignia stamped/painted 4
32 07 36 12 1 116 326 Rubber valve L=42,5MM 4
32 07 36 14 6 792 829 Screw-in valve, RDC 4
32 07 36 14 6 792 827 Screw-in valve, RDC ORANGE 4
32 08 36 14 1 095 389 Valve 4
32 09 36 12 1 120 779 Valve caps 4
32 09 36 11 1 095 436 Valve caps RDC 4
32 02 36 11 6 769 229 Light alloy rim 7JX16 ET:34 4
32 ? 36 11 6 775 615 Light alloy rim 7JX16 ET:34 4
32 03 36 13 1 095 390 Wheel bolt black M12X1,5 20
32 04 36 13 6 768 640 Hub Cap with clipped-on plaque 4
32 02 36 11 6 769 230 Light alloy rim 8JX17 ET:34 4
32 ? 36 11 6 775 616 Light alloy rim 8JX17 ET:34 4
32 02 36 11 6 763 396 Light alloy rim 6JX16 ET:37 4
32 ? 36 11 6 775 636 Light alloy rim 6JX16 ET:37 4
32 02 36 11 6 761 996 Light alloy rim 8JX18 ET:20 4
32 02 36 11 6 761 997 Light alloy rim 9JX18 ET:32 2
32 02 36 11 6 757 375 Light alloy rim “Brilliantline” 9JX20 ET:24 2
32 02 36 11 6 757 376 Light alloy rim “Brilliantline” 10JX20 ET:24 2
32 03 36 13 6 758 730 Wheel bolt black M14X1,5 20
32 ? 36 13 6 781 152 Wheel bolt black M14X1,5 20
32 08 36 14 6 774 590 Valve caps RDC 4
32 06 36 11 1 095 375 Screw-in valve, RDC 4
BMW models for which the BMW wheel style 32 fits: E87+ E36 E46 E90+ E34 E39 E60+ E38 E65+ E36
More images

Will the BMW wheel style 32 fit on your BMW?

Bear in mind that it could be dangerous to run your BMW on tires or wheels they aren’t designed to fit. If you are unsure about your current wheel specifications, please check our BMW wheel fitment chart and guide



Insert your existing BMW wheel and tire specifications, and the sizes of the BMW wheel style 32, and the outcome will be shown on the diagram. The strut shown in the diagram below is for illustration purpose only.

YOUR EXISTING SETUP
Existing Tyre
Existing Wheel

Above values are only examples! If unsure of your current wheel size? Check here!

YOUR NEW SETUP
Existing Tyre
Existing Wheel

Above values are only examples! Change values to view fittment.

YOUR RESULTS

The diagram is only for show to help you visualize your tires and wheel fitment of your new setup.


Tire Width - The width of your tire in millimeters. 195/55ZR15

Tire Profile - The ratio of tire wall width to tire width. 195/55ZR15

Tire Diameter - The diameter of your wheels in inches. 195/55ZR15

Offset - the distance from the center of the wheel to the mounting face in mm. ET20

Rim Width - The width of your rims in inches. 7.5JX17

Inches Original Wheel New Wheel Difference
Diameter %
Circumference %
Sidewall %
Width %
Wheel Revolutions
