BMW wheel style 51

The BMW wheel style 51 is part of bmw’s lineup of original wheel styles.
The bmw Style 51 wheel is available in diameters of 17″ inches, with a bolt pattern of 5×120.
This is the original wheel style for the bmw series E36 and E46, however it might fit other models given the specifications match below with the replacement wheel.The style given to this wheel is best described as Double Spoke.

BMW wheel style 51

BMW wheel style 51 Technical Specifications & Parts

Wheel Style Nr Part Number Part Name Part Details
51 02 85 32 9 408 695 Light alloy rim 8JX17 ET:47 4
51 03 36 11 1 095 410 Light alloy rim 8JX17 ET:47 4
51 04 36 13 6 781 150 Wheel bolt black M12X1,5 16
51 05 36 13 1 094 877 Hub cap 4
51 06 36 13 1 181 080 BMW plaque with adhesive film D=64,5MM 4
51 07 36 12 1 116 326 Rubber valve L=42,5MM 4
51 07 36 14 6 792 829 Screw-in valve, RDC 4
51 08 36 14 1 095 389 Valve 4
51 09 36 12 1 120 779 Valve caps 4
51 09 36 11 1 095 436 Valve caps RDC 4
BMW models for which the BMW wheel style 51 fits: E36 E46 Z3
More images

Will the BMW wheel style 51 fit on your BMW?

Bear in mind that it could be dangerous to run your bmw on tires or wheels they aren’t designed to fit. If you are unsure about your current wheel specifications, please check our bmw wheel fitment chart and guide

Insert your existing bmw wheel and tire specifications, and the sizes of the BMW wheel style 51, and the outcome will be shown on the diagram. The strut shown in the diagram below is for illustration purpose only.

YOUR EXISTING SETUP
YOUR NEW SETUP


Your Results

The diagram is only for show to help you visualize your tires and wheel fitmet of your new setup.


Tire Width - The width of your tire in millimeters. 195/55ZR15

Tire Profile - The ratio of tire wall width to tire width. 195/55ZR15

Tire Diameter - The diameter of your wheels in inches. 195/55ZR15

Inches Original Wheel New Wheel Difference
Diameter %
Circumference %
Sidewall %
Width %
Wheel Revolutions
